Out Diameter:21.3-610mm

Wall Thickness: 1.65-20mm

Length : 3-12m, or according to customer’s requirement

End: Plain End, Beveled End, Treaded

Standard: ASTM 5L, ASTM A53, ASTM A178, ASTM A500/501, ASTM A691, ASTM A252, ASTM A672, EN 10217

Material Grade:
API 5L: PSL1/PSL2 Gr.A, Gr.B, X42, X46, X52, X56, X60, X65, X70
ASTM A53: GR.A, GR.B
EN: S275, S275JR, S355JRH, S355J2H

Surface: Bare, Painting Black, Varnished, Galvanized, Anti-corrosion 3PE PP/EP/FBE coating etc.

Packing: Plastic plugs in both ends, Hexagonal bundles of max. 2,000kg with several steel strips, Two tags on each bundle, Wrapped in waterproof paper, PVC sleeve, and sackcloth with several steel strips, Plastic caps.

Test: Chemical Component Analysis, Mechanical Properties (Ultimate tensile strength, Yield strength, Elongation), Technical Properties (Flattening Test, Bending Test, Hardness Test, Impact Test), Exterior Size Inspection, Hydrostatic Test, NDT TEST ( ET TEST, RT TEST, UT TEST)

Trade Terms: FOB CIF CFR

Payment Terms: FOB 30%T/T, 70% before shipment
CIF 30% pre-payment and the balance to be paid upon B/L (copy)
or Irrevocable 100% L/C at sight

Applications of ERW Pipe：
BEARING PILES
COMBINATION WALLS
THREADED MICROPILE CASING
STRUCTURAL SECTIONS
